x| Materials | Silicone Resin | Color | Clear/ Transparent |
|---|---|---|---|
| Part | Two Part | Sample | Free Samples |
| Packing | 20kg Per Set | Application | Electrical Insulation And Moisture Protection For Low-voltage Applications, Particularly Suitable For Insulating Cables And Wires In Junction Boxes. |
| Name | 2 Component Silicone Gel | Product Name | Two-component Silicone Gel |
| Appearance | Transparent Liquid | Report | RoHS REACH,ISO |
| OEM | Yeah | Keyword | Electric Insulation, Good Waterproof And Moisture Resistance , Silicone Gel |
| Usage | Encapsulation Of Various Modules, Semi-conductor, IGBT, Automotive ECU Module, IC Chip, Weighing Sensor, Waterproof Connector. |
GEL 6605A/B is a two-liquid type clear rugged silicon gel gel that cures to form a cushioned elastic soft
material. It is designed to insulate circuit boards from moisture and other harmful contaminants and to provide insulation against high voltages. Another use is to provide stress relief to protect circuit u and interconnectors from high temperature and mechanical stress.
Features
l 1:1 addition molding high elasticity
l Excellent flexibility, eliminates mechanical stress
l Very low oil permeability after curing, excellent resistance to toxicity
l High temperature electrical insulation is excellent, to provide protection against high pressure
l Excellent aging resistance and weather resistance
l Excellent waterproof, anticorrosive, moisture-proof, chemical medium resistance
Typical Application
l Power modules, such as thyristors, l Solid state relays, diode packages
l Cable junction box filling
l Waterproof junction box fill
l Motor lead box
l Electric vehicle control box
∎Technical Data Table
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
∎Packing Specification
●Part A—10 KG/Bucket
●Part B—10 KG/ Bucket.
∎Transport &Storage
● When stored at or below 25°C in the original unopened containers, this product has a usable life of 12 months from the date of production. Sampling test is necessary for products which exceed shelf life before taking use.
It’s non-dangerous goods, can be transported as normal chemicals, CAUTION leakage during transport.
.∎Directions for Use
Vacuum defoaming can improve the performance of cured product. Seal the remaining products tightly after use. Low temperature will slow the curing speed; heat curing is recommended. It's hard for SI8715 to cure if contact with sulfur, amine or Sn
∎Attention of operation
●Keep away from Children
●Avoid contact with eyes and skin. If contact with your skin, scrub first with soap water or alcohol, then rinse with water. If contact with your eyes, rinse with plenty of water, and seek medical treatment immediately.
● It is forbidden to build on the surface of the wet substrate.
∎Safety Operation Data
MSDS isn't included here. Please read TDS, MSDS and label carefully before operation. You can get MSDS from MAXTECH or other distributors, or mail to service center maxtech@shmaxtech.com
∎Warranty and Liability
All product properties and application details based on information believe to be reliable and accurate. But you still need to test its property and safety before application. The advice we supply don't apply in any circumstances. MAXTECH don't make assurance of any other applications outside the specification until MAXTECH supply a special written guarantee. MAXTECH is only responsible to replace or refund if this product is defective within the warranty period stated above. MAXTECH makes it clear that will not be liable of any accidents.
